CRANKCASE
Oversized high grade cast iron crankase has convenient oil level indicator, oil filling and drain plugs.
CYLINDER AND CYLINDER HEADS
Deep finned cast iron cylinder and heads provide cool operation. Precision honed cylinders for low oil carry over and high performance.
DUCTILE IRON CRANKSHAFT
Dynamically balanced, precision machined and grinded ductile iron crankshaft assures extended running life.
FLYWHEEL
Cooling fan type balanced flywheel provide high volume airflow for cooling the compressors.
PISTON AND CONNECTING RODS
Lightweight aluminium alloy pistons and connecting rods make low stresses on crankshaft and provide high heat transfer capability.
HIGH FLOW VALVES
Stainless steel finger type high flow valves maximizes air delivery can stand on high temperature.
PISTON RINGS
Industrial type compression and oil rings helps to maximize air delivery and low oil carryover.
LOADLESS STARTING
Special loadless starting systems assures longer electric motor lifetime.
INTAKE FILTER AND SILENCERS
Large intake filters and silencers provide quiet operation and maximum particle protection.
BARE COMPRESSOR
• GG 22 cast iron crankcase
• GG 25 cast iron cyclinder and cylinder head
• GGG 60 cast iron well balanced crankshaft
• Light aluminium alloy piston
• Light aluminium alloy connecting rod
• Special design valve system
• Long life bearings
• Cooling fan type balanced flywheel
• Air intake filter and silencer
• Splash lubrication
• Oil level gauge
• Factory filled oil compressor
AIR TANK
• Designed according to CE norms
• Made from special P265GH type pressure vessel steel
• Manuel water drain valve
• Air discharge valve
• Powder coating paint
MOTOR AND SAFETY SYSTEM
• IP 54, F class electric motor
• Blow down valve from 5.5 HP machine for loadless start
• High quality pressure switch
• Non-return valve
• Belt guard
• Pressure relief valve
• Manometer
OPTIONS
• Magnetic thermal switch for starting of up to 4.0kW units, star-delta starter for 5.5~7.5kW units.
• Automatic drain valves for receiver.
