Mã SP: HP-DRY series - Model: OMEGA

Máy Sấy Khí Hấp Thụ HP-DRY series

HP-DRY adsorption dryers have been designed for continuous separation of water vapourfrom compressed air thus reducing dew point. Operation of the dryer requires two columns operated alternately. Adsorption takes place under pressure in the first column while the second column regenerates with a portion of already dried compressed air at ambient pressure. Dryers consists from control valves, controller with LED display and two columns filled with desiccant. Springs in the columns make surethat the desiccant beads will not move during operation. Proven robust design enables efficient and reliable operation, fast installation and simple maintenance.

Yêu Cầu Giá Tốt

    • SĐT: 0948.007.822
    • Mail: yen@ttech.vn

HP-DRY series

HP-DRY adsorption dryers have been designed for continuous separation of water vapourfrom compressed air thus reducing dew point. Operation of the dryer requires two columns operated alternately. Adsorption takes place under pressure in the first column while the second column regenerates with a portion of already dried compressed air at ambient pressure. Dryers consists from control valves, controller with LED display and two columns filled with desiccant. Springs in the columns make surethat the desiccant beads will not move during operation. Proven robust design enables efficient and reliable operation, fast installation and simple maintenance.

HP DRY

Characteristics

operating presure  50, 100, 250,400 bar
 operating temp. range
 1,5 to 50 °C
 pressure dew points  -40 °C
 flow rate  50 to 1600 Nm³h

Applications

• compressed air systems

Technical data

HP DRY 03
